Industrial 18.1" Flat Panel Monitor 39
Publication 6185-UM001B-EN-P
To adjust the luminance of the monitor:
Press and hold either one of the luminance buttons until the luminance is
adjusted as desired.
• The left luminance button reduces the luminance and the right button
increases it.
• The green LED blinks fast when you first press the button and slows
down as you reach the end of the adjustment range.
• When you release the luminance button for three seconds, the amber
LED blinks twice to indicate that your changes have been saved and
will be used each time the monitor is powered ON.
Table E
Interpreting the Luminance LEDs
Green LED Amber LED Condition
On Off Normal Operation - The monitor is receiving a valid video signal.
Off On Signal Not Received - The monitor is not receiving a valid video signal.
On (blinking
slowly) Off Backlight Off - The monitor is still ON but the backlight is powered OFF. Hold
down both buttons for 2 seconds to disable the backlight. Press either button to
enable the backlight.
On (blinking
fast then slow) Off Changing Luminance Setting - When you are pressing one of the luminance
buttons, the LED blinks fast and slows down as you reach the end of the
possible luminance adjustments in that direction. The light stops blinking when
you stop pressing the button, and the amber LED blinks twice when the change
has been saved. Once a luminance setting has been saved, it will be used each
time the monitor is powered ON.
On On (blinking
slowly) Calibration Mode - See instructions below.
To turn off the monitor without turning off the power:
1. Press and hold both buttons for 2 seconds, until the monitor’s
backlight is turned OFF.
2. Press either button to turn the backlight back ON.
