Mounting options (6185-v) – Rockwell Automation 6185-V Industrial 18.1 Inch Flat Panel Monitor User Manual User Manual
Page 20
20
Industrial 18.1" Flat Panel Monitor
Publication 6185-UM001B-EN-P
Mounting Options (6185-V)
There are three main options for mounting the Versa mount monitor.
• Bench top mount arm (mounts on horizontal surfaces using bolts or
table edge clamp)
• Wall mount arm (mounts on vertical surfaces using bolts)
• Bench or wall mount yoke (mounts on horizontal or vertical surfaces
using bolts)
Figure 14
Benchtop Mount Arm (6185-VxxxxxB)
Mounting Clearances
