Bulletin 280/281 Programmable Parameters
3-13
Last PR Fault
0 = None
1 = Hardware Short Circuit
2 = Software Short Circuit
3 = Motor Overload
4 = Reserved
5 = Phase Loss
6 – 12 = Reserved
13 = Control Power Loss
14 = Control Power Fuse
15 = I/O Short
16 = Output Fuse
17 = Overtemp
18= Reserved
19 = Phase Imbalance
20 = Reserved
21 = DNet Power Loss
22 = Internal Comm
23-26 = Reserved
27 = MCB EEPROM
28 = Base EEPROM
29 = Reserved
30 = Wrong Base
31 = Wrong CTs
32-100 = Reserved
Parameter Number
61
Access Rule
GET
Data Type
UINT
Group
Starter Protection
Units
—
MinimumValue
0
Maximum Value
100
Default Value
0
Warning Status
This parameter warns the
user of a condition, without
faulting
Parameter Number
62
Access Rule
GET
Data Type
WORD
Group
Starter Protection
Units
—
MinimumValue
0
Maximum Value
65535
Default Value
0
Bit
Warning
15 14 13 12 11 10
9
8
7
6
5
4
3
2
1
0
X
reserved
X
reserved
X
Phase Loss
X
reserved
X
reserved
X
Control Power
X
IO Warning
X
reserved
X
Phase Imbalance
X
DeviceNet
X
reserved
X
reserved
X
reserved
X
Hardware
X
reserved
X
reserved
