Appendix
B
Bulletin 280/281 CIP Information
Electronic Data Sheets
Electronic Data Sheets (EDS) files are specially formatted ASCII
files that provide all of the information necessary for a configuration
tool (e.g. RSNetWorx™ for DeviceNet™) to access and alter the
parameters of the device. The EDS file contains all of the device
information: number of parameters, groupings, parameter name,
minimum, maximum, and default values, units, data format and
scaling.
EDS files for all the ArmorStart
®
Distributed Motor Controller units
are available from the Internet at
http://www.ab.com/networks/eds.
They may also be built automatically by some configuration tools
since all of the information necessary for a basic EDS file may be
extracted from the ArmorStart Distributed Motor Controller.
DOL Type Product Codes and Name
Strings
Product codes for DOL starters (and DOL Reversing starters) are
based on the Overload relay current rating and the control power
rating of the starter. The following table lists the product codes for the
Bulletin 280 Distributed Motor Controllers:
Table B.1 Bul. 280 Distributed Motor Controller Product Codes and Name
Strings
DOL Reversing Type Product Codes
and Name String
The following table lists the product codes for the Bulletin 281
Distributed Motor Controllers:
Table B.2 Bul. 281 Distributed Motor Controller Product Codes and Name
Strings
280D Device
Type
Product Code
Contactor Size
Code
Overload
Current Rating
Control Power
Voltage
22
0xA1
100C-12
0.5…2.5 A
24V DC
22
0xA2
100C-12
1.1…5.5 A
24V DC
22
0xA3
100C-23
3.2…16 A
24V DC
281D
Device Type
Product
Code
Contactor Size
Code
Overload
Current Rating
Control Power
Voltage
22
0xE1
100C-12
0.5…2.5 A
24V DC
22
0xE2
100C-12
1.1…5.5 A
24V DC
22
0xE3
100C-23
3.2…16 A
24V DC
