Bulletin 280/281 CIP Information
B-3
Identity Object — CLASS CODE
0x0001
The following class attributes are supported for the Identity Object:
Table B.4 Identity Object Class Attributes
Identity Objects
A single instance of the Identity Object is supported. The following
instance attributes are supported.
Table B.5 Identity Object Instance Attributes
The following common services are implemented for the Identity
Object:
Table B.6 Identity Object Common Services
Message Router — CLASS CODE
0x0002
No class or instance attributes are supported. The message router
object exists only to rout explicit messages to other objects.
Attribute ID
Access Rule
Name
Data Type
Value
1
Get
Revision
UINT
1
Attribute ID
Access Rule
Name
Data Type
Value
1
Get
Vendor
UINT
1
2
Get
Device Type
UINT
22 or 133
3
Get
Product Code
UINT
See Table B.1 and Table B.2
4
Get
Revision
Major Revision
Minor Revision
Structure of:
USINT
USINT
Indicates Software Firmware Revision Number
5
Get
Status
WORD
Bit 0 — 0=not owned; 1=owned by master
Bit 2 — 0=Factory Defaulted; 1=Configured
Bit 8 — Minor Recoverable fault
Bit 9 — Minor Unrecoverable fault
Bit 10 — Major Recoverable fault
Bit 11 — Major Unrecoverable fault
6
Get
Serial Number
UDINT
Unique Number for Each Device
7
Get
Product Name
String Length
ASCII String
Structure of:
USINT
STRING
Product code specific
See Table B.1 and Table B.2
8
Get
State
USINT
Returns the value “3=Operational”
9
Get
Configuration Consistency Value
UINT
Unique value depending on output of the parameter
checksum algorithm.
10
Get/Set
Heartbeat Interval
USINT
In seconds. Default = 0
Service
Code
Implemented for:
Service
Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x05
No
Yes
Reset
0x10
No
Yes
Set_Attribute_Single
