Renewal Parts
Figure G.4 Bulletin 284 Safety Base Module Renewal Part Catalog Structure
Base Module Renewal Part
Product Selection
Table G.7 Bulletin 284 Base Module Renewal Part, IP67/NEMA 4, Up to 480V
AC With Conduit Entrance
Table G.8
Bulletin 284 Base Module Renewal Part, IP67/NEMA 4, Up to
480V AC with ArmorConnect™ Connectivity
Table G.9 Motor Cables
Table G.10
Source Brake Cable
Bulletin
Number
Communications
D
DeviceNet™
Enclosure Type
F
Type 4 (IP67)
280
D – F NS – 10 – C
Short-Circuit Protection
Bulletin 140 Current Rating (A)
10
10 A Rated Device
25
25 A Rated Device
Line Media
C
Conduit
R
ArmorConnect™ Power Media
Base
NS
Base Only — no starter
Input Voltage
kW
Hp
Output
Current
Cat. No.
380…480V
50/60 Hz
3-Phase
0.4…2.2
0.5…3.0
1.4…4.0 A
280D-FNS-10-C
3.0
5.0
6.0…7.6 A
280D-FNS-25-C
Input Voltage
kW
Hp
Output
Current
Cat. No.
380…480V
50/60 Hz
3-Phase
0.4…2.2
0.5…3.0
1.4…4.0 A
280D-FNS-10-R
3.0
5.0
6.0…7.6 A
280D-FNS-25-R
Description
Cable Rating
Length m (ft)
Cat. No.
90° M22 Motor
Cordset
IP67/NEMA Type
4
3 m (9.8)
280-MTR22-M3
6 m (19.6)
280-MTR22-M6
14 m (45.9)
280-MTR22-M14
90° M22 Motor
Cordset
(Shielded)
IP67/NEMA Type
4
3 m (9.8)
284-MTRS22-M3
6 m (19.6)
284-MTRS22-M6
14 m (45.9)
284-MTRS22-M14
Description
Cable Rating
Length m (ft)
Cat. No.
90° M25 Source
Brake Cable
IP67/NEMA Type 4
3m (9.8)
285-BRC25-M3
6 m (19.6)
285-BRC25-M6
14 m (45.9)
285-BRC25-M14
