2-20 Installation and Wiring
ArmorStart Safety with
ArmorConnect Connectivity
Three-Phase Power Receptacle
ArmorStart devices with 10 A short
circuit protection rating ArmorStart devices with 25 A short
circuit protection rating
A1/A2 -24V DC
1732DS Safety
I/O Module Output
Control Power from
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
Three-Phase Power Receptacle
A1/A2 -24V DC
1732DS Safety
I/O Module Output
Control Power from
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
Ground
Terminal
Safety Monitor
Input from
1732DS Safety
I/O Module Input
A1/A2 -24V DC
Control Power from
1732DS Safety
I/O Module Output
ArmorStart devices with conduit entrance
Three-Phase Power Receptacle
