Bulletin 284 CIP Information
Electronic Data Sheets
Electronic Data Sheets (EDS) files are specially formatted ASCII
files that provide all of the information necessary for a configuration
tool (e.g., RSNetWorx
™ for DeviceNet™ Revision 3.21 Service Pack
2 or later) to access and alter parameters of the device. The EDS file
contains all of the device information: number of parameter,
groupings, parameter name, minimum, maximum, and default values,
units, data format, and scaling.
EDS files for all the ArmorStart® Distributed Motor Controllers units
are available from the Internet at www.ab.com/networks/eds.
They may also be built automatically by some configuration tools
since much of the information necessary for an EDS file may be
extracted from the ArmorStart Distributed Motor Controller.
VFD Type Product Codes and Name
Strings
Product codes for the Bulletin 284 variable frequency drives are based
on the Horse Power Rating and Supply Voltage rating of the
Distributed Motor Controller. Table C.1 lists the product codes and
name strings for the Bulletin 284 Distributed Motor Controllers:
Table C.1 Bulletin 284 Product Codes and Name Strings
284D
Device
Type
Product
Code
Hp
Supply Voltage
Name String
Drive Type
22
0x192
0.50
480V AC
ArmorStart 284D PF40 480V 0.5 Hp
PF40
22
0x194
1
480V AC
ArmorStart 284D PF40 480V 1 Hp
PF40
22
0x196
2
480V AC
ArmorStart 284D PF40 480V 2 Hp
PF40
22
0x197
3
480V AC
ArmorStart 284D PF40 480V 3 Hp
PF40
22
0x198
5
480V AC
ArmorStart 284D PF40 480V 5 Hp
PF40
