Bulletin 284 CIP Information C-31
The following common services are implemented for the Control
Supervisor Object
Table C.59 Control Supervisor Object Common Services:
Acknowledge Handler Object — CLASS CODE 0x002b
No class attributes are supported for the Acknowledge Handler
Object.
A single instance (Instance 1) of the Acknowledge Handler Object is
supported. The following instance attributes are supported
Table C.60 Acknowledge Handler Instance Attributes:
The following common services are implemented for the
Acknowledge Handler Object
Table C.61 Acknowledge Handler Common Services:
Service
Code Implemented for Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Attribute
ID
Access
Rule
Name
Data
Type
Value
1 Get/Set Acknowledge Timer UINT milliseconds
2 Get Retry Limit USINT 1
3 Get COS Producing Connection Instance UINT 4
Service
Code
Implemented for
Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
