C-8
Bulletin 284 CIP Information
Table C.20 Instance 190 is the 1999-ZCIO Native Format Produced Assembly
Standard Distributed Motor Controller I/O Assemblies
Standard Distributed Motor Controller I/O Assemblies are available
on all Starter Types.
Standard Distributed Motor Controller Output (Consumed) Assemblies
Instance 3 is the required output (consumed) assembly defined in the
DeviceNet Motor Starter Profile.
Table C.21 ODVA Starter
Instance 160 is the default output (consumed) assembly for Bulletin
280/281 Distributed Motor Controllers
Table C.22 Instance 160 — Default Consumed Standard Distributed Motor
Controller.
Instance 162 is the standard output (consumed) assembly with
Network Inputs for Bulletin 280/281 Distributed Motor Controllers
Table C.23 Standard Consumed Starter with Network Inputs.
Instance 190 1799-ZCIO Native Format Produced Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Running
Rev
Running
Fwd
Warning
Tripped
Input 3
Input 2
Input 1
Input 0
1
Reserved
Logic
Enable
Reserved
140M On
HOA
2
Drive In 4
Drive In 3
Drive In 2
Drive In
1
User Out
B
User Out
A
Run Rev
Run
Fwd
3
Reserved
Jog Rev
Jog Fwd
4
Net Out 8
Net Out 7
Net Out 6
Net Out
5
Net Out
4
Net Out
3
Net Out 2
Net Out
1
5
ZIP CCV (Low)
6
ZIP CCV (High)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
—
—
—
—
—
—
—
Run Fwd
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
User Out
B
User Out
A
Fault
Reset
Run Rev
Run Fwd
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
User Out
B
User Out
A
Fault
Reset
Run Rev
Run Fwd
1
Net In 8
Net In 7
Net In 6
Net In 5
Net In 4
Net In 3
Net In 2
Net In 1
2
Net In 16 Net In 15 Net In 14 Net In 13 Net In 12
Net In 11 Net In 10
Net In 9
