Rockwell Automation Publication 750-RM001F-EN-P - February 2012
27
About the PowerFlex Safe Speed Monitor Option Module
Chapter 2
Configuration
Configure the PowerFlex 750-Series safety option by setting the configuration
parameters with a HIM module, DriveExplorer, DriveExecutive, or RSLogix
5000 software.
All of these software configuration tools let you save the configuration and
download it to another PowerFlex 750-Series drive. DriveExecutive and RSLogix
5000 software also let you edit the configuration offline.
RSLogix 5000 software version 20 or later allows you to configure a Logix
controller for Automatic Device Configuration (ADC), a feature that allows the
controller to download the configuration into a new device. When this feature is
used with the safety option, manual steps are required after the controller
downloads the configuration into the safety option.
When the safety option configuration is complete, it can be safety-locked to
prevent unauthorized changes to the safety configuration. If a password was set to
protect the safety configuration, you must enter the password before you can lock
or unlock the configuration. Refer to
for instructions on setting up
and resetting passwords.
If you are using a HIM module, DriveExplorer, Drive Executive, or RSLogix
5000 software to configure the safety option, refer to the PowerFlex 750-Series
Drives Programming Manual, publication
.
Drive
DriveExplorer
DriveExecutive
RSLogix 5000
RSLogix 5000 with
ADC Feature
PowerFlex 753
Frames 1…7
Version 6.02 or later
Version 5.03 or later
Version 16 or later
with Drives AOP v3.01
or later
Not Available
PowerFlex 755
Frames 1…7
Version 6.01 or later
Version 5.01 or later
Version 16 or later
with Drives AOP v2.01
or later
Version 20 or later
PowerFlex 755
Frames 8…10
Version 6.02 or later
Version 5.03 or later
Version 16 or later
with Drives AOP v3.02
or later
Version 20 or later
