Chapter 3 Display Menu Operations
44 Series PM174 Powermeters
Viewing and Changing Setup Items
A second level menu normally consists of three items: the
upper static window indicates the menu name, while the
middle window represents a list of setup parameters you can
scroll through, and the lower item shows the present
parameter value.
To select a parameter you want to view or change:
1. Highlight the middle window by pressing the SELECT
button.
2. Scroll through the parameter list with the UP and DOWN
buttons until the desired parameter name appears.
To change the selected parameter:
1. Press the SELECT button to highlight
the lower item.
2. If a number represents the parameter, adjust it to the
desired value with the UP and DOWN arrow buttons.
When briefly pressed, the button increments or
decrements the number by one. When the button is
pressed continuously, the number is changed
approximately twice per second.
3. If a name represents the parameter, select the desired
option with the UP and DOWN arrow buttons.
4. To store your new selection, press the ENTER button.
5. To leave the parameter unchanged, press the ESC
button.
You will return to the parameter list to select another
parameter or return to the main menu.
To exit the menu, press ESC.
Menu Operations
Basic Device Settings
This menu allows you to configure the basic meter settings
that define the general operating characteristics of the device.
To enter the menu, select the “baSc” entry from the main
menu, and then press the ENTER button.
To select a setup option:
1. Press the SELECT button to activate the middle window.
bASc
4Ln3
ConF
bASc
4Ln3
ConF
S
bASc
1.0
Pt
bASc
1.0
Pt
S
bASc
200.0
Pt
ENERGY
ENTER SELECT
bASc
200.0
Pt THD/TDD
ESC
