Chapter 3 Display Data Display
40 Series PM174 Powermeters
Flicker/Unbalance
4 C.Unb
I% unb
Current negative
sequence unbalance,
percent
Energy Display
Press the ENERGY button. The MVAh, Mvarh, or MWh LED is
illuminated. If TOU registers are configured in the meter, press
the button again to scroll through all active TOU registers. Use
the UP and DOWN arrow buttons to scroll through { XE
"demand" }energy pages.
Along with total energies, per phase energy accumulators are
displayed if phase energy calculation is enabled in the Device
Options menu.
Total and Phase Energies
1 Ac.En.
IP.
MWh Total Wh import
2 rE.En.
IP.
Mvarh Total varh import
3 AP.En.
MVAh Total VAh
4 Ac.En.
EP.
MWh Total Wh export
5 rE.En.
EP.
Mvarh Total varh export
6 Ac.En.
IP.L1.
MWh
Phase L1 Wh import
7 rE.En.
IP.L1.
Mvarh Phase L1 varh import
8 AP.En.
L1.
MVAh Phase L1 VAh
9 Ac.En.
IP.L2.
MWh Phase L2 Wh import
10 rE.En.
IP.L2.
Mvarh Phase L2 varh import
11 AP.En.
L2.
MVAh Phase L2 VAh
12 Ac.En.
IP.L3.
MWh Phase L3 Wh import
13 rE.En.
IP.L3.
Mvarh
Phase L3 varh import
14 AP.En.
L3.
MVAh Phase L3 VAh
TOU Energy Register 1
S
T
ENERGY
ENTER
ENERGY
ENTER
