Chapter 3 Display
Operations Data Display
Series PM174 Powermeters 39
Power Quality/Harmonics Display
Press the PQ/ESC button. The THD/TDD LED is illuminated.
Press the button again to move to the individual harmonics, or
to the flicker and unbalance displays. Use the UP and DOWN
arrow buttons to scroll through harmonics and power quality
measurements.
Note that voltage harmonics readings are line-to-neutral in the
4LN3, 3LN3 and 3BLN3 wiring modes, and line-to-line in all
other modes.
Total Harmonics
1
thd. V1/V12 THD
V2/V23 THD
V3/V31 THD Voltage THD
2
thd. I1 THD
I2 THD
I3 THD Current THD
3
tdd. I1 TDD
I2 TDD
I3 TDD Current TDD
4
HF
I1 K-Factor
I2 K-Factor
I3 K-Factor
Current K-Factor
Individual Voltage Harmonics
1
02H V1/V12 HD%
V2/V23 HD%
V3/V31 HD% Order 2 harmonic
distortion
2
03H V1/V12 HD%
V2/V23 HD%
V3/V31 HD% Order 3 harmonic
distortion
39
40H V1/V12 HD%
V2/V23 HD%
V3/V31 HD% Order 40 harmonic
distortion
Individual Current Harmonics
1
02H I1 HD%
I2 HD%
I3 HD% Order 2 harmonic
distortion
2
03H I1 HD%
I2 HD%
I3 HD% Order 3 harmonic
distortion
39
40H I1 HD%
I2 HD%
I3 HD% Order 40 harmonic
distortion
Flicker/Unbalance
1
Pst V1 Pst
V2 Pst
V3 Pst Short term flicker
2
Plt V1 Plt
V2 Plt
V3 Plt Long term flicker
3 U.Unb
V% unb Voltage negative
sequence unbalance,
percent
S
T
S
T
PQ
ESC
S
T
PQ
ESC
PQ
ESC
S
T
PQ
ESC
