Appendix D Parameters for Monitoring and
142 Series PM174 Powermeters
Designation Description
I3 DMD
I3 Ampere demand
kW IMP BD kW import block demand
kvar IMP BD kvar import block demand
kVA BD kVA block demand
kW IMP SD kW import sliding window demand
kvar IMP SD kvar import sliding window demand
kVA SD kVA sliding window demand
kW IMP ACC DMD kW import accumulated demand
kvar IMP ACC DMD kvar import accumulated demand
kVA ACC DMD kVA accumulated demand
kW IMP PRD DMD kW import predicted sliding window demand
kvar IMP PRD DMD kvar import predicted sliding window demand
kVA PRD DMD kVA predicted sliding window demand
PF IMP@kVA MXDMD PF (import) at Maximum kVA sliding window demand
kW EXP BD kW export block demand
kvar EXP BD kvar export block demand
kW EXP SD kW export sliding window demand
kvar EXP SD kvar export sliding window demand
kW EXP ACC DMD kW export accumulated demand
kvar EXP ACC DMD kvar export accumulated demand
kW EXP PRD DMD kW export predicted sliding window demand
kvar EXP PRD DMD kvar export predicted sliding window demand
HRM DMD Present Harmonic Demands
V1 THD DMD V1/V12 THD demand 2
V2 THD DMD V2/V23 THD demand 2
V3 THD DMD V3/V31 THD demand 2
I1 THD DMD I1 THD demand
I2 THD DMD I2 THD demand
I3 THD DMD I3 THD demand
I1 TDD DMD I1 TDD demand
I2 TDD DMD I2 TDD demand
I3 TDD DMD I3 TDD demand
SUMM ACC DMD Summary (TOU Total) Accumulated Demands
SUM REG1 ACC DMD Summary register #1 demand
SUM REG2 ACC DMD Summary register #2 demand
… …
SUM REG8 ACC DMD
Summary register #8 demand
SUMM BLK DMD Summary (TOU Total) Block Demands
SUM REG1 BLK DMD Summary register #1 demand
SUM REG2 BLK DMD Summary register #2 demand
… …
SUM REG8 BLK DMD
Summary register #8 demand
SUMM SW DMD Summary (TOU Total) Sliding Demands
SUM REG1 SW DMD Summary register #1 demand
SUM REG2 SW DMD Summary register #2 demand
… …
SUM REG8 SW DMD
Summary register #8 demand
ENERGY Total Energy
kWh IMPORT kWh import
kWh EXPORT kWh export
kvarh IMPORT kvarh import
kvarh EXPORT kvarh export
kVAh TOTAL kVAh total
SUMMARY REGS Summary (TOU Total) Energy Registers
SUM REG1 Summary energy register #1
SUM REG2 Summary energy register #2
… …
SUM REG8
Summary energy register #8
PHASE ENERGY Phase Energy
kWh IMP L1 kWh import L1
kWh IMP L2 kWh import L2
kWh IMP L3 kWh import L3
kvarh IMP L1 kvarh import L1
kvarh IMP L2 kvarh import L2
kvarh IMP L3 kvarh import L3
kVAh L1 kVAh total L1
