Appendix B Parameters for Analog Output
134 Series PM174 Powermeters
Appendix B Parameters for Analog Output
The following table lists parameters that can be provided on
the meter’s analog outputs and on the external analog
expander outputs.
Display Code Designation Description
nonE NONE None (output disabled)
1-Cycle Phase Values
rt.U1 V1/12 RT 1 V1/V12 Voltage
rt.U2 V2/23 RT 1 V2/V23 Voltage
rt.U3 V3/31 RT 1 V3/V31 Voltage
rt.U12 V12 RT V12 Voltage
rt.U23 V23 RT V23 Voltage
rt.U31 V31 RT V31 Voltage
rt.C1 I1 RT I1 Current
rt.C2 I2 RT I2 Current
rt.C3 I3 RT I3 Current
1-Cycle Total Values
rt.Ac.P kW RT Total kW
rt.rE.P kvar RT Total kvar
rt.AP.P kVA RT Total kVA
rt.PF PF RT Total PF
rt.PF.LG PF LAG RT Total PF Lag
rt.PF.Ld PF LEAD RT Total PF Lead
rt.U.AG VOLT AVG RT 1 3-phase average L-N/L-L voltage
rt.UL.AG VOLT AVG LL RT 3-phase average L-L voltage
rt.C.AG AMPS AVG RT 3-phase average current
1-Cycle Auxiliary Values
rt.nEU.C In RT In Current
rt.FrEq FREQ RT Frequency
1-Sec Phase Values
Ar.U1 V1/12 AVR 1 V1/V12 Voltage
Ar.U2 V2/23 AVR 1 V2/V23 Voltage
Ar.U3 V3/31 AVR 1 V3/V31 Voltage
Ar.U12 V12 AVR V12 Voltage
Ar.U23 V23 AVR V23 Voltage
Ar.U31 V31 AVR V31 Voltage
Ar.C1 I1 AVR I1 Current
Ar.C2 I2 AVR I2 Current
Ar.C3 I3 AVR I3 Current
1-Sec Total Values
Ar.Ac.P kW AVR Total kW
Ar.rE.P kvar AVR Total kvar
Ar.AP.P kVA AVR Total kVA
Ar.PF PF AVR Total PF
Ar.PF.LG PF LAG AVR Total PF Lag
Ar.PF.Ld PF LEAD AVR Total PF Lead
Ar.U.AG VOLT AVG AVR 1 3-phase average L-N/L-L voltage
Ar.UL.AG VOLT AVG LL AVR 3-phase average L-L voltage
Ar.C.AG AMPS AVG AVR 3-phase average current
1-Sec Auxiliary Values
rt.nEU.C In AVR In Current
rt.FrEq FREQ AVR Frequency
Present Demands
d.P.i kW IMP ACC DMD Accumulated kW import demand
d.P.E kW EXP ACC DMD Accumulated kW export demand
d.q.i kvar IMP ACC DMD Accumulated kvar import demand
d.q.E kvar EXP ACC DMD Accumulated kvar export demand
d.S kVA ACC DMD Accumulated kVA demand
1 In 4LN3, 4LL3, 3LN3, 3LL3, 3BLN3 and 3BLL3 wiring modes, the
voltages will be line-to-neutral; for any other wiring mode, they will be
line-to-line voltages.
