Appendix D Parameters for Monitoring and
Series PM174 Powermeters 143
Designation Description
kVAh L2
kVAh total L2
kVAh L3 kVAh total L3
%HD V1 V1/V12 Harmonic Distortions 2
V1 %HD01 H01 Harmonic distortion
V1 %HD02 H02 Harmonic distortion
… ...
V1 %HD50
H50 Harmonic distortion
%HD V2 V2/V23 Harmonic Distortions 2
V2 %HD01 H01 Harmonic distortion
V2 %HD02 H02 Harmonic distortion
… ...
V2 %HD50
H50 Harmonic distortion
%HD V3 V3/V31 Harmonic Distortions 2
V3 %HD01 H01 Harmonic distortion
V3 %HD02 H02 Harmonic distortion
… ...
V3 %HD50
H50 Harmonic distortion
%HD I1 I1 Harmonic Distortions
I1 %HD01 H01 Harmonic distortion
I1 %HD02 H02 Harmonic distortion
… ...
I1 %HD50
H50 Harmonic distortion
%HD I2 I2 Harmonic Distortions
I2 %HD01 H01 Harmonic distortion
I2 %HD02 H02 Harmonic distortion
… ...
I2 %HD50
H50 Harmonic distortion
%HD I3 I3 Harmonic Distortions
I3 %HD01 H01 Harmonic distortion
I3 %HD02 H02 Harmonic distortion
… ...
I3 %HD50
H50 Harmonic distortion
ANG V1 V1/V12 Harmonic Angles 2
V1 H01 ANG H01 Harmonic angle
V1 H02 ANG H02 Harmonic angle
… ...
V1 H50 ANG
H50 Harmonic angle
ANG V2 V2/V23 Harmonic Angles 2
V2 H01 ANG H01 Harmonic angle
V2 H02 ANG H02 Harmonic angle
… ...
V2 H50 ANG
H50 Harmonic angle
ANG V3 V3/V31 Harmonic Angles 2
V3 H01 ANG H01 Harmonic angle
V3 H02 ANG H02 Harmonic angle
… ...
V3 H50 ANG
H50 Harmonic angle
ANG I1 I1 Harmonic Angles
I1 H01 ANG H01 Harmonic angle
I1 H02 ANG H02 Harmonic angle
… ...
I1 H50 ANG
H50 Harmonic angle
ANG I2 I2 Harmonic Angles
I2 H01 ANG H01 Harmonic angle
I2 H02 ANG H02 Harmonic angle
… ...
I2 H50 ANG
H50 Harmonic angle
ANG I3 I3 Harmonic Angles
I3 H01 ANG H01 Harmonic angle
I3 H02 ANG H02 Harmonic angle
… ...
I3 H50 ANG
H50 Harmonic angle
H1 PHASE Fundamental (H01) Phase Values
V1 H01 V1/V12 Voltage 2
V2 H01 V2/V23 Voltage 2
