Chapter 2 Installation Electrical Installation
18 Series PM174 Powermeters
Electrical Installation
Before installation ensure that all incoming power sources are
shut OFF. Failure to observe this practice can result in serious
or even fatal injury and damage to equipment.
Typical Installation
COM.1
DIGITAL INPUTS
COM.2
RELAYS
-
ANALOG OUTPUTS
ANALOG INPUTS
+
1 2
+ -
Figure 2-15 Typical Installation
