Chapter 3 Display Using the Menus
42 Series PM174 Powermeters
Status Display
8 Cnt.3
Counter #3
9 Cnt.4
Counter #4
10 batt
nor/Lo Backup battery status
(Normal/Low)
Using the Menus
Navigation Buttons
The PM174 has a menu-driven setup. To enter the menus,
press and release the SELECT button.
The SELECT button selects (highlights) an active window in
which you can select or change a desired menu item. The
button operates once it’s briefly pressed and released.
The UP and DOWN arrow buttons scroll through menu items
in the highlighted window forwards and backwards, and allow
changing a highlighted item when entering numbers.
The ENTER button confirms the selection of a menu item or a
number in the highlighted window, thus allowing to enter a
submenu or to store a changed item.
The ESC button is “Escape” leaving the highlighted item
unchanged or returning to the upper level menu.
Selecting Menus
To access the meter menus, press and release the SELECT
button. The primary meter menu is open as shown below. The
menu has three entries:
• StA - Status Display entry
(see ”Status Display” above)
• OPS – Main setup menu entry
allowing to review setup
options
• CHG – Main setup menu entry
allowing to change setups
To enter the Status Display:
1. If the StA window is not highlighted, use the SELECT
button to activate it.
2. Press the ENTER button to enter the Status Display
To review the meter setup options:
ENERGY
ENTER
THD/TDD
ESC
S T
SELECT
StA
CHG
OPS
SELECT
StA
CHG
OPS
SELECT
ENERGY
ENTER
