Appendix
Code table
l
98
LDEDS−CCU210B EN 4.0
Description
Possible settings
Code
Selection
Lenze
Byte
<
ñò
No.
C0410
Linking digital input signals to an
internal device function ...
^ 46
1 RW
EXT
4
0
Not assigned
... Motor V1 (incl. brake)
2
0
Not assigned
... Motor V2 (incl. brake)
3
0
Not assigned
... Motor V3 (incl. brake)
4
0
Not assigned
... Motor V4 (incl. brake)
5
0
Not assigned
... Motor V5 (incl. brake)
6
0
Not assigned
... Motor V6 (incl. brake)
7
0
Not assigned
... Motor V7 (incl. brake)
8
0
Not assigned
... Motor V8 (incl. brake)
9
0
Not assigned
... CW/CCW rotation of motor
l
CW rotation = LOW
l
CCW rotation = HIGH
10
0
Not assigned
Reserved
11
0
Not assigned
... Set fault
12
0
Not assigned
...Acknowledge fault
13
0
Not assigned
... Frequency inverter: change over
parameter set
l
Parameter set 1 = LOW
l
Parameter set 2 = HIGH
14
0
Not assigned
... DC−injection braking
15
0
Not assigned
... Open brake
16
0
Not assigned
... Stop1
17
0
Not assigned
... Stop2
18
0
Not assigned
... Stop3
19
0
Not assigned
... Stop4
20
0
Not assigned
... Frequency limitation 1
21
0
Not assigned
... Frequency limitation 2
22
0
Not assigned
... Frequency limitation 3
23
0
Not assigned
... Frequency limitation 4
24
0
Not assigned
... SensoPart: change over
parameter set
l
Parameter set 1 = LOW
l
Parameter set 2 = HIGH
25
0
Not assigned
... Deactivate control
