Function library
Status messages
8
l
76 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0601 R 2 Status of digital inputs (bit coded)
^ 75
0 65535
Bit 0 Status DIN1 Digital input DIN1
Bit 1 Status DIN2 Digital input DIN2
Bit 2 Status DIN3 Digital input DIN3
Bit 3 Status DIN4 Digital input DIN4
Bit 4 Status DIN5 Digital input DIN5
Bit 5 Status DIN6 Digital input DIN6
Bit 6 Status DIN7 Digital input DIN7
Bit 7 Status DIN8 Digital input DIN8
Bit 8 Status SS1 positive half wave Control bar 1 positive half wave
Bit 9 Status SS1 negative half wave Control bar 1 negative half wave
Bit 10 Status SS1 full−wave Control bar 1 full−wave
Bit 11 Reserved
Bit 12 Status SS2 positive half wave Control bar 2 positive half wave
Bit 13 Status SS2 negative half wave Control bar 2 negative half wave
Bit 14 Status SS2 full−wave Control bar 2 full−wave
Bit 15 Reserved
C0602 R 2 Status of logic operations (bit
coded) ^ 75
0 65535
Bit 0 Status link OR1 OR operations
Bit 1 Status link OR2
Bit 2 Status link OR3
Bit 3 Status link OR4
Bit 4 Status link OR5
Bit 5 Status link OR6
Bit 6 Status link OR7
Bit 7 Status link OR8
Bit 8 Status link AND1 AND operations
Bit 9 Status lnk AND2
Bit 10 Status link AND3
Bit 11 Status link AND4
Bit 12 Status link AND5
Bit 13 Status link AND6
Bit 14 Status link AND7
Bit 15 Status link AND8
C0603 R 1 Status of digital outputs (bit coded) ^ 75
0 255
Bit 0 Status DOUT1 Digital output DOUT1
Bit 1 Status DOUT2 Digital output DOUT2
Bit 2 Reserved
Bit 3 Reserved
Bit 4 Status MS1 positive half wave Message bar 1 positive half wave
Bit 5 Status MS1 negative half wave Message bar 1 negative half wave
Bit 6 Reserved
Bit 7 Reserved
