Page 52: Motor speed v1−v8" function, Function library
Function library
Motor control
"Motor speed V1−V8" function
l
52
LDEDS−CCU210B EN 4.0
8.5
Motor control
8.5.1
"Motor speed V1−V8" function
By the "Motor speed V1−V8" functions (C0410/1 ... C0410/8), 8 speed values for each
parameter set are provided.
ƒ
The functions are activated via digital signal sources (e. g. digital inputs).
– The brake opens automatically.
– The motor is activated with the frequency (C0011/1 ... C0011/8) that is
parameterised respectively.
– If two speeds are activated at the same time, the higher stage has priority.
Example: If V2 and V5 are activated at the same time, V5 is used.
ƒ
If a "Stop function" is active, the "Motor speed V1−V8" function is inhibited. The
motor control is stopped. The motor is braked to V0 via the deceleration ramp of the
stop function (C0434/1 ... C0434/4).
ƒ
If the "Frequency limitation" function is active, the "Motor speed V1−V8" function is
interrupted. The motor is controlled with the corresponding frequency
(C0440/1 ... C440/4).
The acceleration and deceleration times for V1−V8 can be set individually for each drive
frequency (C0012/1 ... C0012/8 and C0013/1 ... C0013/8). The direction of rotation is
controlled via C0410/9. A second parameter set can be activated via C0410/13.
Codes for parameter setting
Code
Possible settings
Description
No.
ñò
< Byte Lenze
Selection
C0010
RW
EXT
4
10000
Conversion factor: speed at 50 Hz
drive frequency
^ 52
0
{mm/min}
65535
C0011
Drive frequency for ...
^ 52
1 RW
EXT
4
0.0
0.0
{Hz}
120.0 ... V1
2
0.0
... V2
3
0.0
... V3
4
0.0
... V4
5
0.0
... V5
6
0.0
... V6
7
0.0
... V7
8
0.0
... V8
C0012
Acceleration time for ...
^ 52
1 RW
EXT
4
50
1
{Hz/s}
255 ... V1
2
50
... V2
3
50
... V3
4
50
... V4
5
50
... V5
6
50
... V6
7
50
... V7
8
50
... V8
