Function library
Digital input signals
Description
l
43
LDEDS−CCU210B EN 4.0
Codes for parameter setting
Code
Possible settings
Description
No.
ñò
< Byte Lenze
Selection
C0406
Switch−on delay of digital input
signals
LOW
ð HIGH ...
^ 42
1 RW
EXT
4
0
0
{ms}
10000 ... DIN1
2
0
... DIN2
3
0
... DIN3
4
0
... DIN4
5
0
... DIN5
6
0
... DIN6
7
0
... DIN7
8
0
... DIN8
9
0
... SS1 positive half wave
10
0
... SS1 negative half wave
11
0
... SS1 full−wave
12
0
Reserved
13
0
... SS2 positive half wave
14
0
... SS2 negative half wave
15
0
... SS2 full−wave
16
0
Reserved
C0407
Switch−off delay of digital input
signals
HIGH
ð LOW ...
^ 42
1 RW
EXT
4
0
0
{ms}
10000 ... DIN1
2
0
... DIN2
3
0
... DIN3
4
0
... DIN4
5
0
... DIN5
6
0
... DIN6
7
0
... DIN7
8
0
... DIN8
9
0
... SS1 positive half wave
10
0
... SS1 negative half wave
11
0
... SS1 full−wave
12
0
Reserved
13
0
... SS2 positive half wave
14
0
... SS2 negative half wave
15
0
... SS2 full−wave
16
0
Reserved
