Appendix
Code table
10
l
100 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0410 (Continuation)
Linking digital input signals to an
internal device function ^ 46
64 HWC match code 1 HWC match code 1
65 HWC match code 2 HWC match code 2
66 HWC match code 3 HWC match code 3
67 HWC match code 4 HWC match code 4
68 HWC match code 5 HWC match code 5
69 HWC match code 6 HWC match code 6
70 HWC match code 7 HWC match code 7
71 HWC match code 8 HWC match code 8
72 HWC match code 9 HWC match code 9
73 HWC match code 10 HWC match code 10
74 HWC match code 11 HWC match code 11
75 HWC match code 12 HWC match code 12
76 HWC match code 13 HWC match code 13
77 HWC match code 14 HWC match code 14
78 HWC match code 15 HWC match code 15
79 HWC match code 16 HWC match code 16
80 Reserved
... ...
95 Reserved
96 HWC−OR1 Result of HWC OR operation
97 HWC−OR2 Result of HWC OR operation
98 HWC−OR3 Result of HWC OR operation
99 HWC−OR4 Result of HWC OR operation
100 HWC−OR5 Result of HWC OR operation
101 HWC−OR6 Result of HWC OR operation
102 HWC−OR7 Result of HWC OR operation
103 HWC−OR8 Result of HWC OR operation
104 Reserved
... ...
252 Reserved
253 Fixed LOW Signal level always is LOW
254 Fixed HIGH Signal level always is HIGH
255 Not assigned
