Technical data
General data and operating conditions
4
l
20 LDEDS−CCU210B EN 4.0
Operating conditions
Ambient conditions
Climatic
Storage IEC/EN 60721−3−1 1K3 (−25 ... +70 °C) < 6 months
1K3 (−25 ... +40 °C) > 6 months
> 2 years: form DC−bus
capacitors
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (0...+45 °C)
> +40 °C: reduce the rated output current by 2.5%/°C.
Pollution EN 61800−5−1 Degree of pollution 2
Site altitude < 4000 m amsl
> 1000 m amsl: reduce the rated output current by
5 %/ 1000 m.
Mechanic
Vibration resistance
Storage Germanischer Lloyd Vibration test 1
Transport EN 60721−3−2 2M2
Operation
EN 60721−3−3 3M4
EN 60721−3−7 7M2
Electric
Mains connection
Mains system
TT, TN
(earthed neutral)
Operation permitted without restrictions.
IT Operation permitted without restrictions.
Motor connection
Length of the motor
cable < 5 m from motor connector
Cable type Shielded servo cable (e. g. LAPP: Ölflex servo, FD−755−CP)
Mounting conditions
Mounting place On monorail overhead conveyors
Mounting position Vertically, control connections laterally on the right
Mounting clearances
at the top Typically 150 mm
The actual free space is determined by the connectors used
and the cable bending radii.
at the bottom
to the sides
