Appendix
Code table
10
l
105 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0451 RW EXT 4 0 "Open brake" function:
maximum activation time
^ 56
0 {s} 1000 l C0451 = 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes if
C0410/15 = LOW
l C0451 > 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes after the time set
if C0410/15 = HIGH
C0460 RW EXT 4 1 SensoPart:
configuration
^ 57
0 SensoPart inactive
1 SensoPart active − 57.6 kBaud
2 SensoPart active − 62.5 kBaud
3 SensoPart active − 38.4 kBaud
4 SensoPart active − 19.2 kBaud
5 SensoPart active − 9.6 kBaud
6 SensoPart active − 4.8 kBaud
C0461 RW EXT 4 500 SensoPart:
distance for quick disconnection ^ 57
0 {mm} 65535
C0462 SensoPart:
stop distance in ...
^ 57
1 RW EXT 4 2000 0 {mm} 65535 ... Parameter set 1
2 2000 ... Parameter set 2
C0463 SensoPart:
hysteresis for stop distance in ...
^ 57
1 RW EXT 4 100 0 {mm} 65535 ... Parameter set 1
2 100 ... Parameter set 2
C0464 SensoPart:
traverse path with creeping speed
VS in ... ^ 57
1 RW EXT 4 50 0 {mm} 65535 ... Parameter set 1
2 50 ... Parameter set 2
C0466 SensoPart:
drive frequency for creeping speed
VS in ... ^ 57
1 RW EXT 4 5.0 0 {Hz} 120.0 ... Parameter set 1
2 5.0 ... Parameter set 2
C0467 SensoPart:
delay time:
start of the acceleration V0
ð VS in
...
^ 57
1 RW EXT 4 1000 0 {ms} 20000 ... Parameter set 1
2 1000 ... Parameter set 2
C0468 SensoPart:
deceleration ramp for stop VS
ð V0
in ...
^ 57
1 RW EXT 4 50 1 {Hz/s} 255 ... Parameter set 1
2 50 ... Parameter set 2
