Function library
Digital output signals
Assignment logic
8
l
51 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0415 (Continuation)
Linking internal status signals to
digital output signal ...
^ 50
Possible values
32 Motor is running
33 Reserved
34 Status On/Off: OFF active
35 Status On/Off: OFF active or fault
active
36 Status On/Off: OFF active or fault
active or Stop 1 active or manual Ir
operation active
37 Reserved
38 Stop 1, 2, 3, 4 active or SensoPart
active
39 Frequency limitation 1, 2, 3, 4 active
or SensoPart active
40 Reserved
41 Reserved
42 SensoPart: Stop active
43 SensoPart: frequency limitation
active
44 Reserved
... ...
50 Reserved
51 Start−up warning or fault active
52 Reserved
... ...
59 Reserved
60 IrDA positioning active
61 IrDA position reached
62 Reserved
... ...
252 Reserved
253 Fixed LOW Signal level always is LOW
254 Fixed HIGH Signal level always is HIGH
255 Not assigned
