Assignment logic
In the assignment logic (C0415) you assign internal status signals to the message bar and
the digital outputs.
Codes for parameter setting
Code
Possible settings
Description
No.
ñò
< Byte Lenze
Selection
C0415
Linking internal status signals to
digital output signal ...
^ 50
1 RW
EXT
4
0
Not assigned
...Digital output DOUT1
2
0
Not assigned
...Digital output DOUT2
3
0
Not assigned
Reserved
4
0
Not assigned
Reserved
5
0
Not assigned
... Message bar1 positive half wave
6
0
Not assigned
... Message bar1 negative half wave
Possible values
0
Not assigned
1
Motor V1 active
2
Motor V2 active
3
Motor V3 active
4
Motor V4 active
5
Motor V5 active
6
Motor V6 active
7
Motor V7 active
8
Motor V8 active
9
Motor CCW rotation active
10
Reserved
11
Fault active
12
Reserved
13
Frequency inverter: parameter set 2
active
14
Reserved
15
Brake is open
16
Stop 1 active
17
Stop 2 active
18
Stop 3 active
19
Stop 4 active
20
Frequency limitation 1 active
21
Frequency limitation 2 active
22
Frequency limitation 3 active
23
Frequency limitation 4 active
24
SensoPart: parameter set 2 active
25
Reserved
...
...
29
Reserved
30
HWC code range active
31
Reserved
