Appendix
Code table
10
l
107 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0491 RW EXT 2 150 IrDA positioning approach path
^ 66
0 {mm} 2000
C0492 RW EXT 4 5.0 IrDA positioning approach speed ^ 66
1 {Hz} 50.0
C0493 RW EXT 1 50 IrDA positioning deceleration time ^ 66
1 {Hz/s} 255
C0495 RW EXT 2 3 IrDA positioning braking distance
correction ^ 66
1 {mm} 100
C0496 RW EXT 2 3 IrDA positioning position window ^ 66
1 {mm} 100
C0500 RW EXT 4 0 Display code for 7−segment display ^ 80
0 Standard display
1 Drive frequency with sign [Hz]
2 DC−bus voltage [V]
3 Motor current [A]
5 Output stage temperature [ °C]
7 Status of the digital inputs and
control bars [hex]
8 Status of the digital outputs and
message bars [hex]
9 SensoPart: distance [mm]
10 Status of the seconds counter [s]
11 HWC command status
12 Status of encoder position [mm]
13 Status of system deviation [mm]
15 IrDA position value [mm]
201 Reserved for customer−specific
displays
C0520 Disposable data memory
6 characters
(e. g. for carriage number)
1 RW EXT 1 0 0 {ASCII} 255 Character 1
2 0 Character 2
3 0 Character 3
4 0 Character 4
5 0 Character 5
6 0 Character 6
C0521 Disposable data memory
8 characters
(e. g. for serial number of carriage)
1 RW EXT 1 0 0 {ASCII} 255 Character 1
2 0 Character 2
3 0 Character 3
4 0 Character 4
5 0 Character 5
6 0 Character 6
7 0 Character 7
8 0 Character 8
