Function library
Monitoring
Anti−collision sensor SensoPart
8
l
60 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0461 RW EXT 4 500 SensoPart:
distance for quick disconnection
^ 57
0 {mm} 65535
C0462 SensoPart:
stop distance in ... ^ 57
1 RW EXT 4 2000 0 {mm} 65535 ... Parameter set 1
2 2000 ... Parameter set 2
C0463 SensoPart:
hysteresis for stop distance in ... ^ 57
1 RW EXT 4 100 0 {mm} 65535 ... Parameter set 1
2 100 ... Parameter set 2
C0464 SensoPart:
traverse path with creeping speed
VS in ... ^ 57
1 RW EXT 4 50 0 {mm} 65535 ... Parameter set 1
2 50 ... Parameter set 2
C0466 SensoPart:
drive frequency for creeping speed
VS in ... ^ 57
1 RW EXT 4 5.0 0 {Hz} 120.0 ... Parameter set 1
2 5.0 ... Parameter set 2
C0467 SensoPart:
delay time:
start of the acceleration V0
ð VS in
...
^ 57
1 RW EXT 4 1000 0 {ms} 20000 ... Parameter set 1
2 1000 ... Parameter set 2
C0468 SensoPart:
deceleration ramp for stop VS
ð V0
in ...
^ 57
1 RW EXT 4 50 1 {Hz/s} 255 ... Parameter set 1
2 50 ... Parameter set 2
C0469 RW EXT 1 0 SensoPart step monitoring: ^ 57
0 Step monitoring inactive
1 Step monitoring active
C0470 RW EXT 1 10 SensoPart step monitoring: ^ 57
2 {s} 20 Error delay
C0472 SensoPart:
distance for switch−over to
approach speed ... ^ 57
1 RW EXT 4 4000 0 {mm} 65535 ... Parameter set 1
2 4000 ... Parameter set 2
C0473 SensoPart:
hysteresis for short distance in ...
^ 57
1 RW EXT 4 100 0 {mm} 65535 ... Parameter set 1
2 100 ... Parameter set 2
C0476 SensoPart:
drive frequency for approach speed
in ...
^ 57
1 RW EXT 4 20.0 0 {Hz} 120.0 ... Parameter set 1
2 20.0 ... Parameter set 2
