Appendix
Code table
10
l
101 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0415 Linking internal status signals to
digital output signal ...
^ 50
1 RW EXT 4 0 Not assigned ...Digital output DOUT1
2 0 Not assigned ...Digital output DOUT2
3 0 Not assigned Reserved
4 0 Not assigned Reserved
5 0 Not assigned ... Message bar1 positive half wave
6 0 Not assigned ... Message bar1 negative half wave
Possible values
0 Not assigned
1 Motor V1 active
2 Motor V2 active
3 Motor V3 active
4 Motor V4 active
5 Motor V5 active
6 Motor V6 active
7 Motor V7 active
8 Motor V8 active
9 Motor CCW rotation active
10 Reserved
11 Fault active
12 Reserved
13 Frequency inverter: parameter set 2
active
14 Reserved
15 Brake is open
16 Stop 1 active
17 Stop 2 active
18 Stop 3 active
19 Stop 4 active
20 Frequency limitation 1 active
21 Frequency limitation 2 active
22 Frequency limitation 3 active
23 Frequency limitation 4 active
24 SensoPart: parameter set 2 active
25 Reserved
... ...
29 Reserved
30 HWC code range active
31 Reserved
