Function library
Operating mode
8
l
41 LDEDS−CCU210B EN 4.0
8.2 Operating mode
The vehicle control system is operated in the "V/f characteristic control" operating mode.
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0015 RW EXT 4 0 Operating mode ^ 41
0 V/f characteristic control
1 Reserved
2 Reserved
C0016 RW EXT 4 400 Mains voltage ^ 41
0 {V} 480
C0017 RW EXT 4 0 Mains frequency ^ 41
0 50 Hz
1 60 Hz
C0018 Switching frequency of the inverter
in ... ^ 41
1 RW EXT 4 2 8 kHz ... Parameter set 1
2 2 8 kHz ... Parameter set 2
Possible values
0 2 kHz
1 4 kHz
2 8 kHz
C0024 V/f characteristic – U-boost voltage
in ... ^ 41
1 RW EXT 4 5.0 1 {%} 25.5 ... Parameter set 1
2 5.0 ... Parameter set 2
C0029 V/f characteristic – base frequency
in ... ^ 41
1 RW EXT 4 50.0 0 {Hz} 120.0 ... Parameter set 1
2 50.0 ... Parameter set 2
