Function library
Motor control
"Open brake" function
8
l
56 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0444 Deceleration ramp Vx ð VLx for ... ^ 55
1 RW EXT 4 50 1 {Hz/s} 255 ... Frequency limitation 1
2 50 ... Frequency limitation 2
3 50 ... Frequency limitation 3
4 50 ... Frequency limitation 4
8.5.4 "Open brake" function
You can also open the motor brake via digital signal sources (C0410/15) without using the
"Motor V1−V8" functions.
In order to prevent an overload of the brake by triggering it for too long, a maximum
triggering time can be parameterised via C0451. After this time has elapsed, the brake
automatically engages even if a trigger signal is available.
If the "Motor V1−V8" functions are active, the motor brake always is open automatically.
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0450 RW EXT 4 0 "Open brake" function:
configuration
^ 56
0 Brake opens immediately Brake opens if C0410/15 = HIGH
1 Brake opens with delay Brake opens if C0410/15 = HIGH
and drive frequency = 0 Hz
C0451 RW EXT 4 0 "Open brake" function:
maximum activation time ^ 56
0 {s} 1000 l C0451 = 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes if
C0410/15 = LOW
l C0451 > 0 s:
– Brake opens if
C0410/15 = HIGH
– Brake closes after the time set
if C0410/15 = HIGH
