Appendix
Code table
10
l
93 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0244 HWC match codes
^ 70
1 RW EXT 1 0 0 201 HWC match code 1
2 HWC match code 2
3 HWC match code 3
4 HWC match code 4
5 HWC match code 5
6 HWC match code 6
7 HWC match code 7
8 HWC match code 8
9 HWC match code 9
10 HWC match code 10
11 HWC match code 11
12 HWC match code 12
13 HWC match code 13
14 HWC match code 14
15 HWC match code 15
16 HWC match code 16
C0245 Logic OR operations for HWC match
codes
^ 70
1 RW EXT 2 0 0 65535 HWC−OR1
2 HWC−OR2
3 HWC−OR3
4 HWC−OR4
5 HWC−OR5
6 HWC−OR6
7 HWC−OR7
8 HWC−OR8
C0250 RW EXT 1 0 HWC code range control mode ^ 70
0 No control
1 Control active
2 Control with pick−up after stop
function
C0251 HWC code range commands ^ 70
1 RW EXT 1 201 1 201 HWC command for lowest variable
speed (Vv_min)
2 HWC command for highest variable
speed (Vv_max)
C0252 HWC code range speeds
^ 70
1 RW EXT 2 500 10 {mm/min} 65535 HWC lowest variable speed
(Vv_min)
2 HWC highest variable speed
(Vv_max)
C0254 RW EXT 1 50 HWC acceleration time for variable
speed Vv ^ 70
1 {Hz/s} 255
C0255 RW EXT 1 50 HWC deceleration time for variable
speed Vv ^ 70
1 {Hz/s} 255
