Appendix
Code table
10
l
96 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0408 Level inversion for digital inputs
à inputs are LOW−active
^ 42
RW EXT 1 0 1 255
Possible values Add values of the inverted inputs:
e. g. DIN1, DIN3 and DIN5 are
LOW−active
à C0408 = 21.
0 No inversion
1 DIN1
2 DIN2
4 DIN3
8 DIN4
16 DIN5
32 DIN6
64 DIN7
128 DIN8
