Troubleshooting and fault elimination
Status display
l
80
LDEDS−CCU210B EN 4.0
Special displays
Via C0500 you can activate some special displays which are shown during operation instead of the
standard displays.
Pos.
Display
Description
1
−
8
8.
8 Drive frequency with sign [Hz]
8
8
8
U DC−bus voltage [V]
8
8.
8
A Motor current [A]
8
8
8
C Output stage temperature [°C]
8
8
8
8 Status of the digital inputs and control bars [hex]
8
8 Status of the digital outputs and message bars [hex]
8
8
8
8 SensoPart: distance [mm]
8
8 Status of the seconds counter [s]
C
8
8
8 HWC command status
8
8
8
8 Status of encoder position value [mm]
−
8
8
8 Status of system deviation with sign [mm]
−
8
8
8 Status of IrDA difference position with sign [mm]
8.
8.
8.
8. User−specific display
Codes for parameter setting
Code
Possible settings
Description
No.
ñò
< Byte Lenze
Selection
C0500
RW
EXT
4
0
Display code for 7−segment display
^ 80
0
Standard display
1
Drive frequency with sign [Hz]
2
DC−bus voltage [V]
3
Motor current [A]
5
Output stage temperature [
°C]
7
Status of the digital inputs and
control bars [hex]
8
Status of the digital outputs and
message bars [hex]
9
SensoPart: distance [mm]
10
Status of the seconds counter [s]
11
HWC command status
12
Status of encoder position [mm]
13
Status of system deviation [mm]
15
IrDA position value [mm]
201
Reserved for customer−specific
displays
