Appendix
Code table
10
l
106 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0469 RW EXT 1 0 SensoPart step monitoring:
^ 57
0 Step monitoring inactive
1 Step monitoring active
C0470 RW EXT 1 10 SensoPart step monitoring: ^ 57
2 {s} 20 Error delay
C0472 SensoPart:
distance for switch−over to
approach speed ... ^ 57
1 RW EXT 4 4000 0 {mm} 65535 ... Parameter set 1
2 4000 ... Parameter set 2
C0473 SensoPart:
hysteresis for short distance in ... ^ 57
1 RW EXT 4 100 0 {mm} 65535 ... Parameter set 1
2 100 ... Parameter set 2
C0476 SensoPart:
drive frequency for approach speed
in ... ^ 57
1 RW EXT 4 20.0 0 {Hz} 120.0 ... Parameter set 1
2 20.0 ... Parameter set 2
C0478 SensoPart:
deceleration ramp Vx
ð VLx for
frequency limitation distance in ...
^ 57
1 RW EXT 4 50 1 {Hz/s} 255 ... Parameter set 1
2 50 ... Parameter set 2
C0480 RW EXT 4 2 Activation method for infrared
remote control Ir−RC
^ 68
0 Ir−RC inactive
1 Activation by key [green] How to activate the manual
infrared operation:
1. Press key [green] for
approx. 1 second.
2. Manual infrared operation is
active.
2 Activation by key [green] and
three−digit code How to activate the manual
infrared operation:
1. Press key [green] for
approx. 1 second.
2. Automatic operation is
interrupted.
3. In the 7−segment display a
three−digit number is shown.
4. Enter this number correctly via
the IR−RC keys within the next 5
seconds.
5. Manual infrared operation is
active.
If the entry is incorrect, the vehicle
control system automatically
switches over to automatic
operation again.
C0481 RW EXT 4 0 Infrared remote control display
switch−over
^ 68
0 IR−RC display switch−over not active
1 IR−RC display switch−over with keys
[
­], [¯], and [F1] active
