Description
Possible settings
Code
Selection
Lenze
Byte
<
ñò
No.
C0602
R
2
Status of logic operations (bit
coded)
^ 75
0
65535
Bit 0
Status link OR1
OR operations
Bit 1
Status link OR2
Bit 2
Status link OR3
Bit 3
Status link OR4
Bit 4
Status link OR5
Bit 5
Status link OR6
Bit 6
Status link OR7
Bit 7
Status link OR8
Bit 8
Status link AND1
AND operations
Bit 9
Status lnk AND2
Bit 10
Status link AND3
Bit 11
Status link AND4
Bit 12
Status link AND5
Bit 13
Status link AND6
Bit 14
Status link AND7
Bit 15
Status link AND8
C0603
R
1
Status of digital outputs (bit coded)
^ 75
0
255
Bit 0
Status DOUT1
Digital output DOUT1
Bit 1
Status DOUT2
Digital output DOUT2
Bit 2
Reserved
Bit 3
Reserved
Bit 4
Status MS1 positive half wave
Message bar 1 positive half wave
Bit 5
Status MS1 negative half wave
Message bar 1 negative half wave
Bit 6
Reserved
Bit 7
Reserved
C0605
R
1
Status of current HWC command
^ 70
0
201
C0606
R
2
Status of encoder position value
^ 70
0
{mm}
65535
C0607
R
2
Status of system deviation
^ 70
0
{mm}
32768
C0610
R
4
SensoPart: current distance
^ 57
0
{mm}
65535
C0612
R
2
Status of IrDA position value [mm]
^ 66
0
{mm}
32768
C0620
R
EXT
4
Parameters: checksum (without
C0520, C0521, C0522 and C0523)
^ 75
0
4294967295
