Electrical installation

Control terminals

l

35

LDEDS−CCU210B EN 4.0

X45 − digital inputs DIN5/DOUT2 − DIN6

Pin

Signal

Description

Data

Connector: socket, 4−pole, M12

1

+24V DC

Supply

HIGH

+16 .... +26.5 V DC

2

1)

DIN5

Digital input 5

LOW

0 ... +4 V

DOUT2

Digital output 2

4 mA

Current per input for 24 V DC

3

GND

Reference potential

max.
200 mA

Permissible current loading per
output
If inductive loads are being
switched, a spark suppressor
must be used at the output!

4

DIN6

Digital input 6

1)

DIN/DOUT cannot be used at the same time!
