Technical data
Rated data
4
l
22 LDEDS−CCU210B EN 4.0
Half wave system
Control bar
Z system No
Number 2
Signal level Full wave
Positive half wave
Negative half wave
Reference voltage or switched
voltage L3
L1 possible with different hardware configuration
Rated voltage 400 ... 480 V AC,
50−60 Hz
Switching threshold 50 Hz: 270 V AC (243 ... 297 V AC)
60 Hz: 330 V AC (297 ... 363 V AC)
Power consumption 1.5 W (400 V AC) for 1 x half wave
Message bar
Number 1
Signal level Full wave
Positive half wave
Negative half wave
Reference voltage or switched
voltage L3
L1 possible with different hardware configuration
Short−circuit protection PTC protection (500 W in series)
Reference voltage 400 ... 480 V
Switching current max. 28 mA AC
Sensor technology
Digital inputs
Number 8
Level HIGH +16 . +26.5 V DC
LOW 0 . 4 V DC
Input current Typ. 4 mA at 24 V DC
Digital outputs
Number 2
Level HIGH +19 . +26.4 V DC
LOW 0 . 4 V DC
Output current Max. 200 mA per
output If inductive loads are switched,
external freewheeling diodes are
required!
Serial interface RS485 SensoPart protocol
Parameter setting and configuration
IrDA interface Serial IrDA interface for parameter setting
Range typ. 300 mm
CAN interface For parameter setting and configuration
Manual control
IR−RC interface Manual operation using infrared remote control
External data memory
Storage space Max. 2 kB Depending on the application
