Appendix
Code table
10
l
94 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0257 RW EXT 4 5.0 HWC control limitation (± of
setpoint frequency)
^ 70
1.0 {Hz} 10.0
C0258 RW EXT 2 200 HWC maximum system deviation ^ 70
2 {mm} 5000
C0261 RW EXT 2 1000 Encoder constant ^ 70
50 {inc/m} 5000
C0264 RW EXT 4 1.5 Voltage control V−boost minimum ^ 70
1 {%} 25.5
C0265 RW EXT 4 5.0 Voltage control V−boost maximum ^ 70
4 {%} 25.5
C0351 R _ 1 0 CAN baud rate
0 500 kbps
1 250 kbps
2 125 kbps
C0390 RW 4 Reserved
C0401 0 Configuration:
response of the non−equivalence
monitoring at the digital inputs ^ 63
1 RW EXT 1 0 0 255 Non−equivalence monitoring 1
2 0 Non−equivalence monitoring 2
3 0 Non−equivalence monitoring 3
4 0 Non−equivalence monitoring 4
Possible values
0 Error in the case of unequal levels at
DINx
1 Error in the case of equal levels at
DINx
C0402 Configuration of non−equivalence
monitoring of the digital inputs ^ 63
1 RW EXT 1 0 0 255 Non−equivalence monitoring 1
2 0 Non−equivalence monitoring 2
3 0 Non−equivalence monitoring 3
4 0 Non−equivalence monitoring 4
Possible values For the non−equivalence monitoring
only two digital inputs can be used
each.
Add values of the inputs monitored
and enter in C0402/x:
e. g. non−equivalence monitoring
for DIN3 and DIN5 = 20.
0 No monitoring
1 DIN1
2 DIN2
4 DIN3
8 DIN4
16 DIN5
32 DIN6
64 DIN7
128 DIN8
