Appendix
Code table
10
l
108 LDEDS−CCU210B EN 4.0
Description Possible settings Code
Selection Lenze Byte < ñò No.
C0522 Disposable data memory
32 characters
(e. g. for freight ID)
1 RW EXT 1 0 0 {ASCII} 255 Character 1
2 0 Character 2
3 0 Character 3
4 0 Character 4
5 0 Character 5
... 0 ...
31 0 Character 31
32 0 Character 32
C0523 R EXT 4 Checksum for C0520, C0521 and
C0522
0 4294967295
C0601 R 2 Status of digital inputs (bit coded) ^ 75
0 65535
Bit 0 Status DIN1 Digital input DIN1
Bit 1 Status DIN2 Digital input DIN2
Bit 2 Status DIN3 Digital input DIN3
Bit 3 Status DIN4 Digital input DIN4
Bit 4 Status DIN5 Digital input DIN5
Bit 5 Status DIN6 Digital input DIN6
Bit 6 Status DIN7 Digital input DIN7
Bit 7 Status DIN8 Digital input DIN8
Bit 8 Status SS1 positive half wave Control bar 1 positive half wave
Bit 9 Status SS1 negative half wave Control bar 1 negative half wave
Bit 10 Status SS1 full−wave Control bar 1 full−wave
Bit 11 Reserved
Bit 12 Status SS2 positive half wave Control bar 2 positive half wave
Bit 13 Status SS2 negative half wave Control bar 2 negative half wave
Bit 14 Status SS2 full−wave Control bar 2 full−wave
Bit 15 Reserved
