8.6.3 Non−equivalence monitoring
By the non−equivalence monitoring you check two digital inputs each with regard to an
unequal input level. If the input level is the same for both digital inputs, an error is reported.
For non−equivalence monitoring, sensors with a normally open contact (no) and a normally
closed contact (nc) are suitable. Both contacts have to be switched at the same time.
There are four non−equivalence monitoring functions, which can be set via C0402. Each
monitoring function can exactly check two digital inputs with regard to each other.
In C0403 you set the error deceleration times.
Codes for parameter setting
Code Possible settings Description
No. ñò < Byte Lenze Selection
C0401 0 Configuration:
response of the non−equivalence
monitoring at the digital inputs ^ 63
1 RW EXT 1 0 0 255 Non−equivalence monitoring 1
2 0 Non−equivalence monitoring 2
3 0 Non−equivalence monitoring 3
4 0 Non−equivalence monitoring 4
Possible values
0 Error in the case of unequal levels at
DINx
1 Error in the case of equal levels at
DINx
C0402 Configuration of non−equivalence
monitoring of the digital inputs ^ 63
1 RW EXT 1 0 0 255 Non−equivalence monitoring 1
2 0 Non−equivalence monitoring 2
3 0 Non−equivalence monitoring 3
4 0 Non−equivalence monitoring 4
Possible values For the non−equivalence monitoring
only two digital inputs can be used
each.
Add values of the inputs monitored
and enter in C0402/x:
e. g. non−equivalence monitoring
for DIN3 and DIN5 = 20.
0 No monitoring
1 DIN1
2 DIN2
4 DIN3
8 DIN4
16 DIN5
32 DIN6
64 DIN7
128 DIN8
C0403 Deceleration of non−equivalence
detection ^ 63
1 RW EXT 4 0 0 {ms} 10000 Deceleration for C0402/1
2 0 Deceleration for C0402/2
3 0 Deceleration for C0402/3
4 0 Deceleration for C0402/4
