12
Error messages
12.2
Possible causes and remedies
92
Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
EtherCAT: Restart by watchdog reset [0x00c86010]
EtherCAT: Internal error [0x00c86011]
EtherCAT: Internal error [0x00c86100]
EtherCAT: Internal error [0x00c86101]
EtherCAT: Internal mapping error [0x00c86110]
EtherCAT: Parameter set invalid [0x00c8641f]
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Communication module is defective.
Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
No response System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Communication module is defective.
Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Internal error.
If the error occurs permanently, please contact Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Internal error.
Send communication module with error description to
Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
The selected PDO mapping is invalid:
• An object not supporting the required properties has
been specified.
• More than 64 bytes of data have been entered/
mapped.
Carry out PDO mapping again.
Configuring process data (PDO mapping) ( 60)
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
No active parameter set could be loaded.
Repeat download of the application (including module).
