6 Commissioning
6.2 Configuring the controller (EtherCAT master)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.2 Configuring the controller (EtherCAT master)
The controller (EtherCAT master) must be configured before communication with the
communication module is possible.
In order to configure EtherCAT networks, you always need a configuration software for the
controller, e.g.:
• Lenze »PLC Designer«
• Beckhoff »TwinCAT«
These are software systems for the programming of control programs, EtherCAT configuration, real-
time execution, and diagnostics.
The basic parameters of the communication module are stored in the internal configuration
memory and can be used by the master for the node identification.
For the node search (fieldbus scan), the corresponding device descriptions of the Lenze device family
are used.
6.2.1 Installing device description files
The current XML device description files required for configuring the EtherCAT node can be found in
the download area at:
www.lenze.com
The following device description file can be installed via the EtherCAT configuration software.

"Controller-based Automation EtherCAT" communication manual
Here you'll find some detailed information relating to the EtherCAT configuration with
the Lenze »PLC Designer«.
Device description file Used for ...
Lenze_E94AYCET_V100_yymmdd.xml Firmware version 1.01 of the E94AYCET communication
module
Lenze_E94AYCET_IO_yyyymmdd.xml From firmware version 2.0 of the E94AYCET
communication module onwards, in connection with the
"CiA402" technology application and Servo Drives 9400
Lenze_E94AYCET_MOTION_yyyymmdd.xml From firmware version 2.0 of the communication
module E94AYCET in connection with Servo Drives 9400
Wildcards in the file name
yyyy
Year
mm Month
dd Day
