13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
106
Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13538
C13539
Parameter | Name:
C13538 | Mapping entries TPDO-8
Data type: UNSIGNED_64
Index: 11037 = 0x2B1D
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the TPDO channel 8.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C13538/1 0 1. Mapping entry TPDO-8 (I-1A07.01)
... ... ...
C13538/32 0 32. Mapping entry TPDO-8 (I-1A07.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13539 | Mapping entries TPDO-9
Data type: UNSIGNED_64
Index: 11036 = 0x2B1C
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the TPDO channel 9.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C13539/1 0 1. Mapping entry TPDO-9 (I-1A08.01)
... ... ...
C13539/32 0 32. Mapping entry TPDO-9 (I-1A08.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
