6 Commissioning
6.1 Before initial switch-on
30
Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6 Commissioning
During commissioning, plant-specific data such as motor parameters, operating parameters,
responses, and parameters for fieldbus communication are defined for the drive. Lenze devices use
codes for this purpose.
The codes of the drive and for communication are saved to the memory module in a non-volatile
data set.
In addition, there are codes for diagnosing and monitoring the stations.
6.1 Before initial switch-on

Note!
When parameterising the communication module, please observe that the code number
depends on the slot of the Servo Drive 9400 in which the communication module has
been inserted.
The first two digits of the code number specify the slot:
• C13nnn for slot MXI1
 Parameters of the communication module for slot MXI1 ( 97)
• C14nnn for slot MXI2
 Parameters of the communication module for slot MXI2 ( 114)
You also have to set the Communication-relevant parameters of the standard device
( 94) .

Stop!
Before you switch on the Servo Drive 9400 and the communication module for the first
time, check the entire wiring for completeness, short circuit and earth fault.
