13 Parameter reference
13.4 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14236 Mapping entries RPDO-6 10339 0x2863 A 32 UNSIGNED_64  
C14237 Mapping entries RPDO-7 10338 0x2862 A 32 UNSIGNED_64  
C14238 Mapping entries RPDO-8 10337 0x2861 A 32 UNSIGNED_64  
C14239 Mapping entries RPDO-9 10336 0x2860 A 32 UNSIGNED_64  
C14240 Mapping entries RPDO-10 10335 0x285F A 32 UNSIGNED_64  
C14484 Active RPDO channel 10091 0x276B A 1 UNSIGNED_8 1  
C14489 Number of RPDO mapping entries 10086 0x2766 A 10 UNSIGNED_8 1  
C14531 Mapping entries TPDO-1 10044 0x273C A 32 UNSIGNED_64  
C14532 Mapping entries TPDO-2 10043 0x273B A 32 UNSIGNED_64  
C14533 Mapping entries TPDO-3 10042 0x273A A 32 UNSIGNED_64  
C14534 Mapping entries TPDO-4 10041 0x2739 A 32 UNSIGNED_64  
C14535 Mapping entries TPDO-5 10040 0x2738 A 32 UNSIGNED_64  
C14536 Mapping entries TPDO-6 10039 0x2737 A 32 UNSIGNED_64  
C14537 Mapping entries TPDO-7 10038 0x2736 A 32 UNSIGNED_64  
C14538 Mapping entries TPDO-8 10037 0x2735 A 32 UNSIGNED_64  
C14539 Mapping entries TPDO-9 10036 0x2734 A 32 UNSIGNED_64  
C14540 Mapping entries TPDO-10 10035 0x2733 A 32 UNSIGNED_64  
C14784 Active TPDO channel 9791 0x263F A 1 UNSIGNED_8 1  
C14789 Number of TPDO mapping entries 9786 0x263A A 10 UNSIGNED_8 1  
C14850 All words to master 9725 0x25FD A 32 UNSIGNED_16 1 
C14851 All words from master 9724 0x25FC A 32 UNSIGNED_16 1 
C14852 All words to standard device 9723 0x25FB A 32 UNSIGNED_16 1 
C14853 All words from standard device 9722 0x25FA A 32 UNSIGNED_16 1 
C14861 Bus state 9714 0x25F2 E 1 UNSIGNED_16 1 
C14864 Active station address 9711 0x25EF E 1 UNSIGNED_16 1 
C14867 Display: Most recent emergency data 9708 0x25EC E 1 OCTET_STRING 
C14870 Cycle time display 9705 0x25E9 E 1 UNSIGNED_32 1 
C14879 Bus error 9696 0x25E0 E 1 UNSIGNED_32 
C14880 Resp. to communication failure 9695 0x25DF A 1 UNSIGNED_8 1  
C14881 Response time when exiting
'Operational'
9694 0x25DE E 1 UNSIGNED_16 1  
C14882 Display of PDO watchdog time 9693 0x25DD E 1 UNSIGNED_32 1 
C14883 DC active 9692 0x25DC E 1 UNSIGNED_8 1 
C14884 Base device synchronisation status 9691 0x25DB E 1 UNSIGNED_8 1 
C14885 Clear process data 9690 0x25DA E 1 UNSIGNED_8 1  
C14892 Process data mode 9683 0x25D3 E 1 UNSIGNED_8 1  
C14899 Station alias 9676 0x25CC E 1 UNSIGNED_16 1  
C14900 Firmware product type 9675 0x25CB E 1 VISIBLE_STRING 
C14901 Firmware compilation date 9674 0x25CA E 1 VISIBLE_STRING 
C14902 Firmware version 9673 0x25C9 E 1 VISIBLE_STRING 
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
