13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
120
Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14532
C14533
Parameter | Name:
C14532 | Mapping entries TPDO-2
Data type: UNSIGNED_64
Index: 10043 = 0x273B
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the TPDO channel 2.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C14532/1 0 1. Mapping entry TPDO-2 (I-1A01.01)
... ... ...
C14532/32 0 32. Mapping entry TPDO-2 (I-1A01.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14533 | Mapping entries TPDO-3
Data type: UNSIGNED_64
Index: 10042 = 0x273A
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the TPDO channel 3.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C14533/1 0 1. Mapping entry TPDO-3 (I-1A02.01)
... ... ...
C14533/32 0 32. Mapping entry TPDO-3 (I-1A02.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
