Lenze E94AYCET - Manual (Page 101)

Lenze · E94AYCET communication module (EtherCAT®) · Communication Manual · DMS 9.0 EN · 02/2014 · TD17
101
13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13239
C13240
Parameter | Name:
C13239 | Mapping entries RPDO-9
Data type: UNSIGNED_64
Index: 11336 = 0x2C48
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the RPDO channel 9.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C13239/1 0 1. Mapping entry RPDO-9 (I-1608.01)
... ... ...
C13239/32 0 32. Mapping entry RPDO-9 (I-1608.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13240 | Mapping entries RPDO-10
Data type: UNSIGNED_64
Index: 11335 = 0x2C47
This code is used device-internally and must not be written by the user!
Subcodes 1 ... 32 specify the mapping for the RPDO channel 10.
• Servo Drives 9400 exclusively support mapping objects with a data length of 8 bits (1 byte) or a multiple of this
value. Incompatible objects must be mapped to variables with a compatible data length.
• The master must have the same mapping entries as the slave.
 Structure of the mapping codes ( 64)
Value is bit-coded: Info
Bit 0 Bit 0
... ...
Bit 63 Bit 63
Subcodes Lenze setting Info
C13240/1 0 1. Mapping entry RPDO-10 (I-1609.01)
... 0 ...
C13240/32 0 32. Mapping entry RPDO-10 (I-1609.20)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
